Product Advantages
• With advanced design and exquisite manufacturing process, the engine features high reliability and durability, adaptable to high-strength and heavy-duty operations under severe working conditions.
• High-pressure fuel pump enables complete combustion under high injection pressure, featuring low energy loss, strong power, high fuel adaptability and lower emissions.
• Holset supercharger with integral wastegate offers low-speed response and dynamic performance.
• With integral cylinder design, engine parts are about 25% less than similar products, featuring lower failure rate and easier maintenance.
• The cylinder liner adopts plateau honing cross hatch and corrosion-resistant high nickel cast iron piston, which significantly reduces engine oil loss and improves durability and service life.
• With advanced design, the power per liter is increased up to 23.4 kW / liter.
• The three-stage filter ensures balanced particle dispersion, protects main components of the fuel system and maximizes engine life.
• The electronic control system intelligently switches to operation modes according to the environment and operating conditions. It has self-diagnosis, alarm and remote monitoring functions.
• The mature intelligent electronic control technology improves the overall performance of the engine. The engine specifications can be customized according to application requirements.
Product Portfolio
| Model |
Emission standard
|
Rated power output
(kW@RPM)
|
Max. Torque
(N.m@rpm)
|
Cylinders |
Displacement (L) |
Aspiration |
| QSC8.3-C215-30 |
NS III/EU StageIIIA |
160@2200 |
980@1350 |
6 |
8.3 |
charged, inter-cooled |
| QSC8.3-C220-30 |
NS III/EU StageIIIA |
162@2200 |
950@1350 |
6 |
8.3 |
charged, inter-cooled |
| QSC8.3-C240-30 |
NS III/EU StageIIIA |
179@2200 |
1040@1350 |
6 |
8.3 |
charged, inter-cooled |
| QSC8.3-C260-30 |
NS III/EU StageIIIA |
194@2200 |
1135@1350 |
6 |
8.3 |
charged, inter-cooled |
| QSC8.3-C260-31 |
NS III/EU StageIIIA |
194@2400 |
1080@1500 |
6 |
8.3 |
charged, inter-cooled |
