Product Advantages
• With advanced design and exquisite manufacturing process, the engine features high reliability and durability, adaptable to high-strength and heavy-duty operations under severe working conditions.
• High-pressure fuel pump enables complete combustion under high injection pressure, featuring low energy loss, strong power, high fuel adaptability and lower emissions.
• Holset supercharger with integral wastegate offers low-speed response and dynamic performance.
• With integral cylinder design, parts are about 25% less than similar products, featuring lower failure rate and easier maintenance.
• The cylinder liner adopts plateau honing cross hatch and corrosion-resistant high nickel cast iron piston, which significantly reduces engine oil loss and improves durability and service life.
• With advanced design, the power per liter is increased up to 23.4 kW / liter.
• The three-stage filter ensures balanced particle dispersion, protects main components of the fuel system and maximizes engine life.
Product Portfolio
| Model |
Rated power output
(kW@RPM)
|
Peak torque
(N.m@RPM)
|
Cylinders |
Displacement (L) |
Aspiration |
| 6CTA8.3-M188 |
138@2328 |
152@2400 |
6 |
8.3 |
charged, inter-cooled |
| 6CTA8.3-M205 |
151@2328 |
166@2400 |
6 |
8.3 |
charged, inter-cooled |
| 6CTA8.3-M220 |
164@1800 |
180@1885 |
6 |
8.3 |
charged, inter-cooled |
| 6CT8.3-GM115 |
115@1500 |
126@1500 |
6 |
8.3 |
Ordinary charged |
| 6CT8.3-GM129 |
129@1800 |
142@1800 |
6 |
8.3 |
Ordinary charged |
| 6CTA8.3-GM155 |
155@1500 |
170@1500 |
6 |
8.3 |
charged, inter-cooled |
| 6CTA8.3-GM175 |
175@1800 |
193@1800 |
6 |
8.3 |
charged, inter-cooled |
